8444 0605000

Active

Belden Inc.

CABLE 4COND 22AWG CHROME

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 4COND 22AWG CHROME

Technical Specifications

Parameters and characteristics for this part

Specification	8444 0605000

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	4.7 mm
Jacket (Insulation) Diameter [diameter]	0.185 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Chrome
Number of Conductors	4
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Ratings	UL Style 2576
Usage	Audio, Instrumentation, Control
Wire Gauge	22 AWG

Part	Cable Type	Operating Temperature [Min]	Operating Temperature [Max]	Usage	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Material	Number of Conductors	Conductor Strand [custom]	Conductor Strand [custom]	Wire Gauge	Ratings	Conductor Insulation	Jacket Color	Length	Length
Belden Inc. 8444 0605000	Multi-Conductor	-20 C	80 C	Audio Control Instrumentation	Poly-Vinyl Chloride (PVC)	4.7 mm	0.185 in	Copper Tinned	4	7	30 AWG	22 AWG	UL Style 2576	Poly-Vinyl Chloride (PVC)	Chrome
Belden Inc. 8444 060U1000	Multi-Conductor	-20 C	80 C	Audio Control Instrumentation	Poly-Vinyl Chloride (PVC)	4.7 mm	0.185 in	Copper Tinned	4	7	30 AWG	22 AWG	UL Style 2576	Poly-Vinyl Chloride (PVC)	Chrome	1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	5000	$ 1.14

General part information

4 Conductor Multi-Conductor Cable Chrome 22 AWG 5000' (1524.0m)
