CRJ064-1-SMT
ActiveSame Sky (Formerly CUI Devices)
RJ JACK, 1 PORT, 4P4C, 6U, UNSHI
CRJ064-1-SMT
ActiveSame Sky (Formerly CUI Devices)
RJ JACK, 1 PORT, 4P4C, 6U, UNSHI
Description
General part information
CRJ064-1-SMT
Jack Modular Connector 4p4c (RJ9, RJ10, RJ22) Vertical Unshielded
Technical Specifications
Parameters and characteristics for this part
| Specification | CRJ064-1-SMT |
|---|---|
| Connector Type | Jack, RJ10, RJ22, RJ9 |
| Contact Finish | Gold |
| Contact Finish Thickness | 6 µin |
| Contact Material | Phosphor Bronze |
| Housing Material | Nylon 9T, PA9T, Polyamide |
| LED Color | Does Not Contain LED |
| Mounting Type | Panel Mount, Flange |
| Number of Contacts | 4 |
| Number of Ports | 1 |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Orientation | Vertical |
| Shielding | Unshielded |
| Tab Direction | User Selectable |
| Termination | Solder |
