LC2D65AEHE
ActiveCONTACTOR, LC2D, 65 A, DIN RAIL, PANEL, 690 VAC, 3PST-NO, 3 POLE, 37 KW
LC2D65AEHE
ActiveCONTACTOR, LC2D, 65 A, DIN RAIL, PANEL, 690 VAC, 3PST-NO, 3 POLE, 37 KW
Description
General part information
LC2D65AEHE
The LC2D65AEHE from Schneider Electric is a TeSys D Green three pole reversing contactor. It is approved by EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, EN/IEC 60947-5-1 standards. TeSys D contactors are designed for perfect integration in control systems. It is used for motor control and resistive load applications.
Technical Specifications
Parameters and characteristics for this part
| Specification | LC2D65AEHE |
|---|---|
| Coil Voltage (Max) | 130 VAC/DC |
| Coil Voltage (Min) | 48 VDC |
| Coil Voltage (Type) | AC, DC |
| Contact Form | A, PST-NO, Form, 3 |
| Contact Rating (Current) | 65 A |
| Features | Auxiliary Contacts |
| Mounting Type | Chassis Mount, DIN Rail |
| Operate Time | 65 ms |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -40 °C |
| Pin Count | 3 pins |
| Release Time | 120 ms |
| Switching Voltage AC (Max) | 690 VAC |
| Termination Style | Screw Terminal |
