270202010
ActiveRose Enclosures
BOX PLASTIC GRAY 7.35"L X 4.17"W
270202010
ActiveRose Enclosures
BOX PLASTIC GRAY 7.35"L X 4.17"W
Description
General part information
270202010
Box Plastic, Polyamide Gray Hand Held, Split Sides 7.346" L x 4.165" W (186.60mm x 105.80mm) X 1.969" (50.00mm)
Technical Specifications
Parameters and characteristics for this part
| Specification | 270202010 |
|---|---|
| Area (L x W) | 30.6 in² |
| Color | Gray |
| Container Type | Box |
| Design | Split Sides, Hand Held |
| Features | PCB Supports |
| Height | 1.969 in |
| Material | Polyamide, Plastic |
| Material Flammability Rating | UL94 V-2 |
| Ratings | IP65 |
| Size / Dimension Length | 7.346 in |
| Size / Dimension Width | 4.165 in |
