G8020L12B1+6-RSR
ActiveMechatronics Fan Group
FAN AXIAL 80X20.8MM 12VDC WIRE
G8020L12B1+6-RSR
ActiveMechatronics Fan Group
FAN AXIAL 80X20.8MM 12VDC WIRE
Description
General part information
G8020L12B1+6-RSR
FAN AXIAL 80X20.8MM 12VDC WIRE
Technical Specifications
Parameters and characteristics for this part
| Specification | G8020L12B1+6-RSR |
|---|---|
| Air Flow | 31 CFM |
| Approval Agency | CE, TUV, cUL, UL |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Speed Sensor (Tach), PWM Control, Thermal Overload Protector (TOP) |
| Noise | 25 dB |
| RPM | 2500 RPM |
| Size / Dimension Height | 80 mm |
| Size / Dimension Length | 80 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.1 in H2O |
| Termination | 4 Wire Leads |
| Termination Leads Count | 4 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 12 VAC |
| Weight | 0.185 lb |
| Width | 20.8 mm |
