Specification	2901833

1st Connector	SC Duplex
2nd Connector	ST
2nd Connector Count	2 pcs
Bend Radius	60 mm
Cable Diameter	0.22 "
Cable Type	Break, Out
Color - Cable	Yellow
Color - Connectors	Black
Fiber Cladding Diameter	125 µm
Fiber Core Diameter	9 µm
Jacket (Insulation) Material	Flame Retardant Non-Corrosive (FRNC)
Length - Overall	6.6 ft
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-5 °C
Type	OS2, Duplex, Singlemode

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources
