Description
General part information
GFE128064E-BNFB-03
Graphic LCD Display Module Transflective STN - Super-Twisted Nematic Parallel
Technical Specifications
Parameters and characteristics for this part
| Specification | GFE128064E-BNFB-03 |
|---|---|
| Background Color | Yellow, Green |
| Backlight Color | Yellow, Green |
| Backlight Type | LED |
| Controller Type | NT7066U-F00 |
| Display Mode | Transflective |
| Display Type | STN - Super-Twisted Nematic |
| Dot Pitch Height | 0.7 mm |
| Dot Pitch Width | 0.6 mm |
| Dot Size Height | 0.66 mm |
| Dot Size Width | 0.56 mm |
| Interface | Parallel |
| Viewing Area Height | 16 mm |
| Viewing Area Width | 64.5 mm |
