9L Type Series

Part	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Rated	RPM	Weight	Bearing Type	Features	Air Flow	Width	Power (Watts)	Termination Leads Count	Termination Type	Termination	Approval Agency	Static Pressure	Fan Type	Size / Dimension Height	Size / Dimension Shape	Size / Dimension Length	Noise	Lifetime	Material - Blade	Current Rating	Material - Frame	Voltage Range (Max)	Voltage Range (Min)
Sanyo Denki America Inc. 109L5724H5D01	-4 °F	158 °F	24 VAC	3050 RPM	1.7 lbs	Ball	Locked Rotor Sensor	226 CFM	51 mm	13.92 W	3	Wire Leads	3 Wire Leads	CSA TUV UL	0.551 in H2O	Tubeaxial	150 mm	Rectangular/Rounded	172 mm	52 dB	100000 Hrs	Plastic	580 mA	Aluminum	27.6 VDC	20.4 VDC
Sanyo Denki America Inc. 109L5724H501	-4 °F	158 °F	24 VAC	3050 RPM	1.7 lbs	Ball	Speed Sensor (Tach)	226 CFM	51 mm	13.92 W	3	Wire Leads	3 Wire Leads	CSA TUV UL	0.551 in H2O	Tubeaxial	150 mm	Rectangular/Rounded	172 mm	52 dB	100000 Hrs	Plastic	580 mA	Aluminum	27.6 VDC	20.4 VDC
Sanyo Denki America Inc. 109L5724M502	-4 °F	158 °F	24 VAC	2000 RPM	1.7 lbs	Ball		148 CFM	51 mm	4.8 W	2 leads	Wire Leads	2 Wire Leads	CSA TUV UL	0.271 in H2O	Tubeaxial	150 mm	Rectangular/Rounded	172 mm	41 dB	100000 Hrs	Plastic	0.2 A	Aluminum	27.6 VDC	20.4 VDC
Sanyo Denki America Inc. 109L5724M501	-4 °F	158 °F	24 VAC	2000 RPM	1.7 lbs	Ball	Speed Sensor (Tach)	148 CFM	51 mm	4.8 W	3	Wire Leads	3 Wire Leads	CSA TUV UL	0.271 in H2O	Tubeaxial	150 mm	Rectangular/Rounded	172 mm	41 dB	100000 Hrs	Plastic	0.2 A	Aluminum	27.6 VDC	20.4 VDC
