CFM-8015BF-130-301
ActiveSame Sky (Formerly CUI Devices)
DC FAN AXIAL BALL BEARING 12V 10.8V TO 13.2V 34.85CFM 30.1DB 80 X 80 X 15.4MM BOX
CFM-8015BF-130-301
ActiveSame Sky (Formerly CUI Devices)
DC FAN AXIAL BALL BEARING 12V 10.8V TO 13.2V 34.85CFM 30.1DB 80 X 80 X 15.4MM BOX
Description
General part information
CFM-8015BF-130-301
Fan Tubeaxial 12VDC Square - 80mm L x 80mm H Ball 34.9 CFM (0.977m³/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-8015BF-130-301 |
|---|---|
| Air Flow | 34.9 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Noise | 30.1 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 3.12 W |
| RPM | 3000 RPM |
| Size / Dimension Height | 80 mm |
| Size / Dimension Length | 80 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.1 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 12 VAC |
| Width | 15.4 mm |
