Specification	SPA101M0EB

Applications	General Purpose
Capacitance	100 µF
ESR (Equivalent Series Resistance)	9 mOhm
Height - Seated (Max)	0.071 in
Lifetime	1000 Hrs
Mounting Type	Surface Mount
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Package / Case	2917 (7343 Metric)
Ripple Current	3 A
Size / Dimension Length	0.287 in
Size / Dimension Width	0.169 in
Surface Mount Land Length	0.287 in
Surface Mount Land Width	0.169 in
Tolerance	20 %
Type	Polymer
Voltage - Rated	2.5 V
