B25632B1127K100
ActiveEPCOS - TDK Electronics
CAP FILM 120UF 10% 1.1KV RADIAL
B25632B1127K100
ActiveEPCOS - TDK Electronics
CAP FILM 120UF 10% 1.1KV RADIAL
Description
General part information
B25632B1127K100
120 µF Film Capacitor 1100V (1.1kV) Radial, Can
Technical Specifications
Parameters and characteristics for this part
| Specification | B25632B1127K100 |
|---|---|
| Applications | DC Filtering, DC Link |
| Capacitance | 120 µF |
| ESR (Equivalent Series Resistance) | 1.4 mOhm |
| Height - Seated (Max) | 2.598 in |
| Lead Spacing | 1.772 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 3.346 in |
| Termination | Screw Terminals |
| Tolerance | 10 % |
| Voltage Rating - DC | 1.1 kVDC |
