Specification	CA3KN22MD

Coil Voltage	220 V
Contact Form	B, PST-2NO/2NC, Form, A, 2
Contact Rating (Current)	10 A
Mounting Type	Chassis Mount, DIN Rail
Must Operate Voltage	176 VAC
Must Release Voltage	22 VDC
Operating Temperature (Max)	50 °C
Operating Temperature (Min)	-25 °C
Pin Count	4
Switching Voltage AC (Max)	690 VAC
Termination Style	Screw Terminal

tesys-d Series

Part	Mounting Type	Contact Rating (Current)	Must Release Voltage	Termination Style	Must Operate Voltage	Switching Voltage AC (Max)	Coil Voltage	Pin Count	Contact Form	Operating Temperature (Min)	Operating Temperature (Max)	Operate Time	Release Time	Features	Switching Voltage DC (Max)	Coil Type	Relay Type	Approval Agency
SCHNEIDER ELECTRIC CA3KN31MD	Chassis Mount DIN Rail	10 A	22 VDC	Screw Terminal	176 VAC	690 VAC	220 V	4	1 3 A B Form PST-3NO/1NC	-25 °C	50 °C
SCHNEIDER ELECTRIC LC1D09FD	Chassis Mount DIN Rail	9 A	11 VDC	Screw Terminal	77 VAC	690 VAC	110 V	3 pins	3 A Form PST-NO	-40 °C	70 °C	72.45 ms	24 ms	Auxiliary Contacts Diode	300 VDC
SCHNEIDER ELECTRIC LC2D12BL	Chassis Mount DIN Rail	25 A	2.4 V	Screw Terminal	19.2 V	690 VAC	24 VDC	3 pins	3 A Form PST-NO	-40 °C	60 °C			Auxiliary Contacts	300 VDC
SCHNEIDER ELECTRIC LC1D128D7	Chassis Mount DIN Rail	25 A	12.6 VAC	Screw Terminal	35.7 VAC	690 VAC	42 V	4	4 Form A PST-NO	-40 °C	70 °C	22 ms	19 ms	Auxiliary Contacts	300 VDC
SCHNEIDER ELECTRIC CAD32Q7	DIN Rail	10 A	114 VAC	Screw Terminal	323 VAC	690 VAC	380 VAC	5	2 3 A B Form PST-3NO/2NC	-40 °C	70 °C	22 ms	17 ms			Non Latching	General Purpose	CB CCC CE CSA EAC UKCA UL
SCHNEIDER ELECTRIC LC1D258D7	Chassis Mount DIN Rail	40 A	12.6 VAC	Screw Terminal	35.7 VAC	690 VAC	42 V	4	4 Form A PST-NO	-40 °C	70 °C	22 ms	19 ms	Auxiliary Contacts
SCHNEIDER ELECTRIC LC1D115B7	Chassis Mount	115 A		Screw Terminal		1000 VAC	24 VDC	3 pins	3 A Form PST-NO	-40 °C	60 °C			Auxiliary Contacts Diode
SCHNEIDER ELECTRIC LC1DT25ED	Chassis Mount DIN Rail	25 A	4.8 VAC	Screw Terminal	33.6 VAC	690 VAC	48 V	4	4 Form A PST-NO	-40 °C	70 °C	72.45 ms	24 ms	Auxiliary Contacts Diode	300 VDC
SCHNEIDER ELECTRIC LC1D25FD	Chassis Mount DIN Rail	25 A	11 VDC	Screw Terminal	77 VAC	690 VAC	110 V	3 pins	3 A Form PST-NO	-40 °C	70 °C	72.45 ms	24 ms	Auxiliary Contacts Diode	300 VDC
SCHNEIDER ELECTRIC LC2D18F7	Chassis Mount DIN Rail	18 A	33 VAC	Screw Terminal	88 V	690 VAC	110 V	3 pins	3 A Form PST-NO	-40 °C	70 °C	22 ms	19 ms	Auxiliary Contacts	300 VDC
