5AK330KABAH
ObsoleteKYOCERA AVX
CAP CER 33PF 100V NP0 RADIAL
5AK330KABAH
ObsoleteKYOCERA AVX
CAP CER 33PF 100V NP0 RADIAL
Description
General part information
5AK330KABAH
33 pF ±10% 100V Ceramic Capacitor C0G, NP0 Radial, Disc
Technical Specifications
Parameters and characteristics for this part
| Specification | 5AK330KABAH |
|---|---|
| Applications | General Purpose |
| Capacitance | 33 pF |
| Height - Seated (Max) | 0.157 in |
| Lead Spacing | 0.197 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -30 °C |
| Package / Case | Disc, Radial |
| Size / Dimension Diameter | 0.197 in |
| Temperature Coefficient | NP0, C0G |
| Tolerance | 10 % |
| Voltage - Rated | 100 VAC/DC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
