TM5SDO2S
ActiveSCHNEIDER ELECTRIC
MOD. 2DO 100-240VAC 1.0 A CODED 3WIRES ROHS COMPLIANT: YES
TM5SDO2S
ActiveSCHNEIDER ELECTRIC
MOD. 2DO 100-240VAC 1.0 A CODED 3WIRES ROHS COMPLIANT: YES
Description
General part information
TM5SDO2S
Output Module DIN Rail 100 ~ 240VAC
Technical Specifications
Parameters and characteristics for this part
| Specification | TM5SDO2S |
|---|---|
| Approval Agency | C-Tick, GOST, CSA, cULus |
| For Use With/Related Products | Modicon TM5 Series |
| Ingress Protection | IP20 |
| Mounting Type | DIN Rail |
| Number of Outputs | 2 |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -10 °C |
| Output Type | Relay |
| Termination Style | Screw Terminal |
| Type | Output Module |
| Voltage - Supply (Maximum) | 240 VAC |
| Voltage - Supply (Minimum) | 100 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
