TML 15115
ObsoleteTraco Power
AC/DC CONVERTER 15V 15W
TML 15115
ObsoleteTraco Power
AC/DC CONVERTER 15V 15W
Description
General part information
TML 15115
Enclosed AC DC Converters 1 Output 15V 1A 90 ~ 264 VAC, 85 ~ 370 VDC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | TML 15115 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cURus, CE |
| Current - Output (Max) | 1 A |
| Efficiency | 80 % |
| Features | Universal Input |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -25 °C |
| Package Leads | 5 Leads |
| Package Name | 8-DIP Module |
| Power (Watts) | 15 W |
| Size / Dimension Height | 0.87 in |
| Size / Dimension Length | 2.91 in |
| Size / Dimension Width | 2.13 in |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Input (DC) Maximum | 370 V |
| Voltage - Input (DC) Minimum | 85 VDC |
| Voltage - Output 1 | 15 V |
