2441545-1
ActiveTE Connectivity AMP Connectors
RF / COAXIAL CONNECTOR, SMA COAXIAL, STRAIGHT FLANGED JACK, SOLDER, 50 OHM, BERYLLIUM COPPER
2441545-1
ActiveTE Connectivity AMP Connectors
RF / COAXIAL CONNECTOR, SMA COAXIAL, STRAIGHT FLANGED JACK, SOLDER, 50 OHM, BERYLLIUM COPPER
Description
General part information
2441545-1
SMA Connector, Jack, 50 ohm, Screw, 27 GHz, Cable-to-Board, 1 Position, Printed Circuit Board, Panel Mount, -55 – 150 °C [-67 – 302 °F], Straight
Technical Specifications
Parameters and characteristics for this part
| Specification | 2441545-1 |
|---|---|
| Center Contact Material | Beryllium Copper |
| Connector Style | SMA |
| Connector Type | Recepture, Female Socket |
| Contact Termination | Solder |
| Fastening Type | Threaded |
| Frequency - Max | 27 GHz |
| Housing Color | Silver |
| Impedance | 50 Ohm |
| Mounting Type | Panel Mount, Surface Mount |
| Number of Ports | 1 |
| Shield Termination | Solder |
