CFM-4020BF-2110-381
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 40X20MM 24VDC WIRE
CFM-4020BF-2110-381
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 40X20MM 24VDC WIRE
Description
General part information
CFM-4020BF-2110-381
Fan Tubeaxial 24VDC Square - 40mm L x 40mm H Ball 13.8 CFM (0.386m³/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-4020BF-2110-381 |
|---|---|
| Air Flow | 13.8 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Current Rating | 120 mA |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 38.1 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 2.88 W |
| RPM | 11000 RPM |
| Size / Dimension Height | 40 mm |
| Size / Dimension Length | 40 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.55 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 24 VAC |
| Voltage Range (Max) | 26.4 VDC |
| Voltage Range (Min) | 21.6 VDC |
| Width | 20 mm |
