TDG1026A-6C
ActivePasternack
PANEL MNT COUPLER 6X6 STRAIGHT
TDG1026A-6C
ActivePasternack
PANEL MNT COUPLER 6X6 STRAIGHT
Description
General part information
TDG1026A-6C
Modular Coupler Connector Jack, 6p6c (RJ11) To Jack, 6p6c (RJ11) Cat3 Unshielded
Technical Specifications
Parameters and characteristics for this part
| Specification | TDG1026A-6C |
|---|---|
| Contact Finish | Gold |
| Contact Finish Thickness | 30 µin |
| Contact Material | Phosphor Bronze |
| Convert From (Adapter End) | 6p6c (RJ11), Jack |
| Convert To (Adapter End) | 6p6c (RJ11), Jack |
| Housing Material | ABS, Acrylonitrile Butadiene Styrene |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | 0 °C |
| Ratings | Cat3 |
| Shielding | Unshielded |
| Type | Coupler |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
