VTX-121-3015-224
ActiveVigortronix
1.5VA ENCAPSULATED TRANSFORMER 230V -24V
VTX-121-3015-224
ActiveVigortronix
1.5VA ENCAPSULATED TRANSFORMER 230V -24V
Description
General part information
VTX-121-3015-224
1.5VA ENCAPSULATED TRANSFORMER 230V -24V
Technical Specifications
Parameters and characteristics for this part
| Specification | VTX-121-3015-224 |
|---|---|
| Center Tap | No |
| Current - Output (Max) | 31 mA |
| Height - Seated (Max) | 24 mm |
| Mounting Type | PCB |
| Power - Max | 1.5 W |
| Primary Winding(s) | Single |
| Secondary Winding(s) | Dual |
| Size / Dimension Length | 32.6 mm |
| Size / Dimension Width | 27.6 mm |
| Termination Style | PC Pin |
| Type | Laminated Core |
| Voltage - Isolation | 4200 VDC |
| Voltage - Primary | 230 V |
| Voltage - Secondary (Full Load) (Parallel) | 24 V |
| Voltage - Secondary (Full Load) (Series) | 48 V |
| Weight | 0.419 lb |
