Description
General part information
COM-19102
4 Ohms General Purpose Speaker 10 W 58 Hz ~ 20 kHz Top Round
Technical Specifications
Parameters and characteristics for this part
| Specification | COM-19102 |
|---|---|
| Distortion Rating | 5 % |
| Distortion Rating Power | 5 W |
| Efficiency - dBA | 85 dBA |
| Efficiency - Testing | 10 W |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Frequency - Self Resonant | 58 Hz |
| Frequency Range (Max) | 20 kHz |
| Frequency Range (Min) | 58 Hz |
| Height - Seated (Max) | 1.22 in |
| Impedance | 4 Ohms |
| Material - Magnet | Nd-Fe-B N40 |
| Port Location | Top |
| Power - Max | 25 W |
| Power - Rated | 10 W |
| Shape | Round |
| Size / Dimension Diameter | 1.969 in |
| Technology | Magnetic |
| Termination | Wire Leads |
| Type | General Purpose |
