PR03000201508JAC00
ActiveVishay Dale
RES 1.5 OHM 5% 3W AXIAL
PR03000201508JAC00
ActiveVishay Dale
RES 1.5 OHM 5% 3W AXIAL
Description
General part information
PR03000201508JAC00
1.5 Ohms ±5% 3W Through Hole Resistor Axial Automotive AEC-Q200, Flame Retardant Coating, Fusible, Safety Metal Film
Technical Specifications
Parameters and characteristics for this part
| Specification | PR03000201508JAC00 |
|---|---|
| Composition | Metal Film |
| Features | Flame Retardant Coating, Safety, Fusible, Automotive AEC-Q200 |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 200 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Power (Watts) | 3 W |
| Resistance | 1.5 Ohm |
| Size / Dimension Diameter | 0.205 in |
| Size / Dimension Length | 0.657 in |
| Temperature Coefficient | 250 ppm/°C |
| Temperature Coefficient (Highest) | 250 ppm/°C |
| Temperature Coefficient (Lowest) | -250 ppm/°C |
| Tolerance | 5 % |
