009176001011106
ActiveKYOCERA AVX
CONN SSL IDC CONTACT 20AWG SLDR
009176001011106
ActiveKYOCERA AVX
CONN SSL IDC CONTACT 20AWG SLDR
Description
General part information
009176001011106
20 AWG SSL Contact, IDC Solder Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 009176001011106 |
|---|---|
| Connector Type | Contact, IDC |
| Contact Finish | Tin |
| Contact Material | Phosphor Bronze |
| Current Rating (Per Contact) | 10 A |
| Features | Cap (Cover) |
| Housing Color | White |
| Housing Material | PA46, Polyamide, Nylon 4/6 |
| Mating Cycles | 3 cycles |
| Mounting Type | Surface Mount |
| Number of Positions | 1 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Style | Cable/Wire, Board |
| Termination | Solder |
| Voltage Rating | 250 V |
| Wire Gauge | 20 AWG |
