1403784
ActivePhoenix Contact
CONN DISTRIBUTOR 5POS SILVER IDC
1403784
ActivePhoenix Contact
CONN DISTRIBUTOR 5POS SILVER IDC
Description
General part information
1403784
5 (4 + PE) Position Circular Connector Distributor IDC
Technical Specifications
Parameters and characteristics for this part
| Specification | 1403784 |
|---|---|
| Backshell Material, Plating | Nylon, Polyamide (PA) |
| Cable Opening (Max) | 0.433 in |
| Cable Opening (Min) | 0.236 in |
| Color | Gray, Black |
| Connector Type | Distributor |
| Contact Finish - Mating | Silver |
| Contact Material | Copper |
| Current Rating | 20 A |
| Fastening Type | Threaded |
| Features | Backshell |
| Ingress Protection Description | Dust Tight, Water Resistant, Waterproof |
| Ingress Protection IP Rating | IP69K, IP68, IP66 |
| Insert Material | PA, Nylon, Polyamide |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 5 |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -40 °C |
| Position Types | PE |
| Primary Material | Plastic |
| Shell Material | Nylon, Polyamide (PA) |
| Termination | IDC |
