FLAG66M0257KH
ActiveKYOCERA AVX
NEW
FLAG66M0257KH
ActiveKYOCERA AVX
NEW
Description
General part information
FLAG66M0257KH
250 µF Film Capacitor 480V Polypropylene (PP), Metallized Radial, Can
Technical Specifications
Parameters and characteristics for this part
| Specification | FLAG66M0257KH |
|---|---|
| Applications | RFI Suppression, EMI |
| Capacitance | 250 µF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| Height - Seated (Max) | 9.803 in |
| Lead Spacing | 1.181 in |
| Mounting Type | Chassis, Stud Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 3.346 in |
| Termination | Threaded, Male |
| Tolerance | 10 % |
| Voltage Rating - AC | 480 VAC |
