Specification	LC1D150FD

Coil Voltage	110 V
Contact Form	A, PST-NO, Form, 3
Contact Rating (Current)	150 A
Features	Suppressor, Auxiliary Contacts
Mounting Type	Chassis Mount, DIN Rail
Must Operate Voltage	82.5 VDC
Must Release Voltage	16.5 VDC
Operate Time	35 ms
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-40 °C
Pin Count	3 pins
Release Time	75 ms
Switching Voltage AC (Max)	1000 VAC
Switching Voltage DC (Max)	300 VDC
Termination Style	Screw Terminal
