Specification	2-6609008-5

Accomodates a Fuse	No
Approval Agency	VDE, CSA, UL
Connector Style	IEC 320-C14
Connector Type	Male Blades, Receptacle
Current Rating - Appliance Inlet	10 A
Current Rating - Filter	10 A
Filter Application	Commercial
Filter Subtype	EMI, RFI
Filter Type	Filtered
Mounting Type	Panel Mount, Snap-In
Number of Positions	3
Panel Cutout Description	Variable Size
Panel Thickness (Max)	0.068 in
Panel Thickness (Min)	0.031 in
Termination	Wire Leads
Voltage Rating - Appliance Inlet	250 VAC

6609008 Series

Part	Panel Thickness (Max)	Panel Thickness (Min)	Connector Style	Filter Type	Filter Subtype	Filter Application	Mounting Type	Connector Type	Panel Cutout Description	Accomodates a Fuse	Termination Probe Tip OD	Termination	Current Rating - Filter	Number of Positions
TE Connectivity AMP Connectors 1-6609008-7	0.068 in	0.031 in	IEC 320-C14	Filtered	EMI RFI	Commercial	Panel Mount Snap-In	Male Blades Receptacle	Variable Size	No	0.25 in	Quick Connect	3 A	3
