KHR4-T227 6.0 OHM 5%
ObsoleteBourns Inc.
RES CHAS MNT 6 OHM 5% 200W
KHR4-T227 6.0 OHM 5%
ObsoleteBourns Inc.
RES CHAS MNT 6 OHM 5% 200W
Description
General part information
KHR4-T227 6.0 OHM 5%
6 Ohms ±5% 200W Thick Film Chassis Mount Resistor
Technical Specifications
Parameters and characteristics for this part
| Specification | KHR4-T227 6.0 OHM 5% |
|---|---|
| Coating | Epoxy Coated |
| Composition | Thick Film |
| Height - Seated (Max) | 0.476 in |
| Housing Type | Epoxy Coated |
| Lead Style | M4 Threaded |
| Mounting Feature | Flanges |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | SOT-227-4 |
| Power (Watts) | 200 W |
| Resistance | 6 Ohm |
| Size / Dimension Length | 1.496 in |
| Size / Dimension Width | 1.024 in |
| Temperature Coefficient | 100 ppm/°C |
| Tolerance | 5 % |
