FL1P-8NJ-2-R110V
ActiveMallory Sonalert Products Inc.
LED RED 8MM NUT 110VAC/DC
FL1P-8NJ-2-R110V
ActiveMallory Sonalert Products Inc.
LED RED 8MM NUT 110VAC/DC
Description
General part information
FL1P-8NJ-2-R110V
LED Panel Indicator Red Diffused 35° 99V ~ 121V 20mA Quick Connect - 0.110" (2.8mm)
Technical Specifications
Parameters and characteristics for this part
| Specification | FL1P-8NJ-2-R110V |
|---|---|
| Current | 20 mA |
| Ingress Protection | IP50 |
| Lamp Color | Red |
| Lens Color | Red |
| Lens Diameter | 8 mm |
| Lens Style | Round, Domed Top |
| Lens Transparency | Diffused |
| Millicandela Rating (Max) | 1500 mcd |
| Millicandela Rating (Min) | 1000 mcd |
| Panel Cutout Dimension | 0.32 " |
| Panel Cutout Shape | Round |
| Quick Connect Size (0.110") | 0.11 in |
| Ratings | AC, DC |
| Termination Style | Quick Connect |
| Type | LED |
| Viewing Angle | 35 ° |
| Voltage (Max) | 121 V |
| Voltage (Min) | 99 V |
