1116-R120-CW
ActiveVisual Communications Company - VCC
PMI LED 18MM 120V TAB RED MS
1116-R120-CW
ActiveVisual Communications Company - VCC
PMI LED 18MM 120V TAB RED MS
Description
General part information
1116-R120-CW
LED Panel Indicator Red Clear 120V 9.5mA Quick Connect
Technical Specifications
Parameters and characteristics for this part
| Specification | 1116-R120-CW |
|---|---|
| Current | 9.5 mA |
| Lamp Color | Red |
| Lens Color | White |
| Lens Diameter | 18.5 mm |
| Lens Style | Round, Domed Top |
| Lens Transparency | Clear |
| Panel Cutout Dimension | 0.69 " |
| Panel Cutout Shape | Round |
| Ratings | AC |
| Termination Style | Quick Connect |
| Type | LED |
| Voltage | 120 V |
