1393546-8

Obsolete

TE Connectivity ALCOSWITCH Switches

SWITCH DIP SPST

Search across all available documentation for this part.

Obsolete

TE Connectivity ALCOSWITCH Switches

SWITCH DIP SPST

Technical Specifications

Parameters and characteristics for this part

SWITCH DIP SPST

Part	Number of Positions	Mounting Type	Length	Length	Actuator Level	Termination Style	Pitch [x]	Pitch	Pitch [x]	Circuit	Height Above Board	Height Above Board	Washable
TE Connectivity ALCOSWITCH Switches 1393546-8	8	Through Hole	0.8 in	20.32 mm	Raised	PC Pin	0.1 in	Full	2.54 mm	SPST	0.319 in	8.1 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Dip Switch SPST 8 Position Through Hole Actuator
