9626-3-5

Active

3M (TC)

TAPE ADHSV TRNSFR CLR 3"X5YDS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

9626-3-5

Active

3M (TC)

TAPE ADHSV TRNSFR CLR 3"X5YDS

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	9626-3-5

Adhesive	Acrylic
Backing, Carrier	Paper
Color	Clear
Length	4.6 m
Length	15 ft
Length	5 yd
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	70 °F
Storage/Refrigeration Temperature	21 °C
Tape Type	Adhesive Transfer
Temperature Range [Max]	38 °C
Temperature Range [Max]	100 °F
Temperature Range [Min]	21 °C
Temperature Range [Min]	70 °F
Thickness	5.2 mils
Thickness	0.132 mm
Thickness	0.0052 "
Thickness - Adhesive	2 mils
Thickness - Adhesive	0.051 mm
Thickness - Adhesive [x]	0.002 "
Thickness - Backing, Carrier	3.2 mils
Thickness - Backing, Carrier	0.0032 "
Thickness - Backing, Carrier	0.081 mm
Width [x]	76.2 mm
Width [x]	3 in

9626 Series

...

Part	Shelf Life Start	Color	Tape Type	Adhesive	Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature	Shelf Life	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive [x]	Length	Length	Length	Temperature Range	Temperature Range	Thickness	Thickness	Thickness	Width [y]	Width [y]	Width	Width	Width	Length [x]	Length [x]	Width [x]	Width [x]	Temperature Range [Max]	Temperature Range [Min]	Temperature Range [Max]	Temperature Range [Min]
3M (TC) 3M 9626 11" X 60YD	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "	60 yds	55 m	180 ft	93 °C	200 °F	5.2 mils	0.132 mm	0.0052 "	279.4 mm	11 in
3M (TC) 3M 9626 2" X 10.5"-50	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "		266.7 mm	10.5 in	93 °C	200 °F	5.2 mils	0.132 mm	0.0052 "	50.8 mm	2 "
3M (TC) 3M 9626 8.625" X 1.25"-25	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "		31.75 mm	1.25 in	93 °C	200 °F	5.2 mils	0.132 mm	0.0052 "				8.63 in	219.08 mm
3M (TC) 3M 9626 2" X 5"-50	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "				93 °C	200 °F	5.2 mils	0.132 mm	0.0052 "	50.8 mm	2 "				5 in	127 mm
3M (TC) 3M 9626 4" X 6"-25	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "		152.4 mm	6 in	93 °C	200 °F	5.2 mils	0.132 mm	0.0052 "								4 "	101.6 mm
3M (TC) 3M 9626 3" X 60YD	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "	60 yds	55 m	180 ft	93 °C	200 °F	5.2 mils	0.132 mm	0.0052 "								3 in	76.2 mm
3M (TC) 3M 9626 CIRCLE-1.500"-100	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "				93 °C	200 °F	5.2 mils	0.132 mm	0.0052 "			38.1 mm	1.5 "
3M (TC) 3M 9626 3" X 10.5"-50	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "		266.7 mm	10.5 in	93 °C	200 °F	5.2 mils	0.132 mm	0.0052 "								3 in	76.2 mm
3M (TC) 3M 9626 1" X 6"-100	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "		152.4 mm	6 in	93 °C	200 °F	5.2 mils	0.132 mm	0.0052 "								1 in	25.4 mm
3M (TC) 9626-3-5	Date of Manufacture	Clear	Adhesive Transfer	Acrylic	Paper	3.2 mils	0.0032 "	0.081 mm	70 °F	21 °C	24 Months	2 mils	0.051 mm	0.002 "	5 yd	4.6 m	15 ft			5.2 mils	0.132 mm	0.0052 "								3 in	76.2 mm	38 °C	21 °C	100 °F	70 °F

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 27.04

Description

General part information

9626 Series

Adhesive Transfer Tape Acrylic Adhesive Clear 3.00" (76.20mm) X 15' (4.6m) 5 yds

Documents

Technical documentation and resources
