1707672
ActivePhoenix Contact
TERM BLOCK PLUG 2POS 3.81MM
1707672
ActivePhoenix Contact
TERM BLOCK PLUG 2POS 3.81MM
Description
General part information
1707672
2 Position Terminal Block Plug, Female Sockets 0.150" (3.81mm) 90° Free Hanging (In-Line)
Technical Specifications
Parameters and characteristics for this part
| Specification | 1707672 |
|---|---|
| Color | Green |
| Contact Mating Finish | Tin |
| Current - IEC | 8 A |
| Insulation Height | 0.752 in |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Pitch | 0.15 in |
| Plug Wire Entry Angle | 90 ° |
| Positions Per Level | 2 |
| Screw Size | M2 |
| Termination Style | Screw - Rising Cage Clamp |
| Torque - Screw (Maximum) | 0.25 Nm |
| Torque - Screw (Minimum) | 0.22 Nm |
| Type | Female Sockets, Plug |
| Wire Strip Length | 7 mm |
