EDC10-30-PCB
ActiveEaton - Electronics Division
FUSE EV 30A 500VAC/DC PCB
EDC10-30-PCB
ActiveEaton - Electronics Division
FUSE EV 30A 500VAC/DC PCB
Description
General part information
EDC10-30-PCB
30A 500 VAC 500 VDC Fuse Cartridge Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | EDC10-30-PCB |
|---|---|
| Applications | Electrical, Industrial |
| Approval Agency | cURus |
| Breaking Capacity (AC) | 3 kA |
| Breaking Capacity (DC) | 10 kA |
| Current Rating | 30 A |
| DC Cold Resistance | 0.003 Ohms |
| Fuse Type | Cartridge |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial Bend Cylinder |
| Size / Dimension Diameter | 0.484 in |
| Size / Dimension Length | 1.315 in |
| Voltage Rating - AC | 500 V |
| Voltage Rating - DC | 500 V |
