85969-6
ActiveTE Connectivity AMP Connectors
CONN SOCKET 20-24AWG CRIMP GOLD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
85969-6
ActiveTE Connectivity AMP Connectors
CONN SOCKET 20-24AWG CRIMP GOLD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 85969-6 | 85969 Series |
|---|---|---|
| Contact Finish | Gold | Tin, Gold |
| Contact Finish Thickness | 15 µin | 15 - 78 µin |
| Contact Finish Thickness | 0.38 µm | 0.38 - 1.98 µm |
| Contact Termination | Crimp | Crimp |
| Pin or Socket | Socket | Socket |
| Wire Gauge [Max] | 24 AWG | 24 AWG |
| Wire Gauge [Min] | 20 AWG | 20 AWG |
85969 Series
CONN SOCKET 20-24AWG CRIMP TIN
| Part | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Pin or Socket | Contact Termination | Wire Gauge [Min] | Wire Gauge [Max] |
|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors 85969-9 | Tin | 78 µin | 1.98 µm | Socket | Crimp | 20 AWG | 24 AWG |
TE Connectivity AMP Connectors 85969-8 | Gold | 30 Áin | 0.76 Ám | Socket | Crimp | 20 AWG | 24 AWG |
TE Connectivity AMP Connectors 85969-6 | Gold | 15 µin | 0.38 µm | Socket | Crimp | 20 AWG | 24 AWG |
TE Connectivity AMP Connectors 1-85969-9 | Gold | 15 µin | 0.38 µm | Socket | Crimp | 20 AWG | 24 AWG |
TE Connectivity AMP Connectors 85969-2 | Gold | 30 Áin | 0.76 Ám | Socket | Crimp | 20 AWG | 24 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.57 | |
| 10 | $ 0.53 | |||
| 25 | $ 0.53 | |||
| 50 | $ 0.51 | |||
| 100 | $ 0.44 | |||
| 250 | $ 0.40 | |||
| 500 | $ 0.38 | |||
| 1000 | $ 0.33 | |||
| 2500 | $ 0.33 | |||
| Tape & Reel (TR) | 50000 | $ 0.27 | ||
Description
General part information
85969 Series
Socket Contact Gold 20-24 AWG Crimp
