Description
General part information
C315C103J5R5HA
Ceramic Capacitor
Technical Specifications
Parameters and characteristics for this part
| Specification | C315C103J5R5HA |
|---|---|
| Applications | Bypass, Decoupling |
| Capacitance | 10000 pF |
| Height - Seated (Max) | 0.183 in |
| Lead Spacing | 0.1 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Size / Dimension Length | 0.15 in |
| Size / Dimension Width | 0.1 in |
| Temperature Coefficient | X7R |
| Tolerance | 5 % |
| Voltage - Rated | 50 V |
