Specification	1415391-1

Approval Agency	VDE, cURus
Coil Current	18.5 mA
Coil Type	Latching, Single Coil
Coil Voltage	6 VAC
Contact Form	C, 1, SPDT, Form
Contact Material	Silver Nickel (AgNi)
Contact Rating (Current)	5 A
Load - Max Switching (Apparent Power)	2000 VA
Mounting Type	Through Hole
Must Operate Voltage	9 VDC
Operate Time	8 ms
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Relay Type	General Purpose
Release Time	8 ms
Switching Voltage AC (Max)	400 VAC
Termination Style	PC Pin

SCHRACK Miniature PCB Relay PE bistable Series

Part	Operating Temperature (Min)	Operating Temperature (Max)	Relay Type	Operate Time	Load - Max Switching (Apparent Power)	Coil Current	Form A Count	Contact Form	Approval Agency	Coil Type	Mounting Type	Release Time	Termination Style	Must Operate Voltage	Switching Voltage AC (Max)	Contact Rating (Current)	Coil Voltage	Contact Material	Coil Resistance	Seal Rating	Must Release Voltage
TE Connectivity AMP Connectors 4-1415535-6	-40 °C	85 °C	General Purpose	8 ms	2000 VA	40 mA	1	SPST-NO	cURus VDE	Non Latching	Through Hole	8 ms	PC Pin	3.8 VDC	400 VAC	6 A	5 V	Silver Nickel (AgNi)	125 Ohms
TE Connectivity AMP Connectors 9-1415389-1	-40 °C	85 °C	General Purpose	8 ms	2000 VA	110 mA		1 C Form SPDT	cURus VDE	Latching Single Coil	Through Hole	8 ms	PC Pin	1.65 VDC	400 VAC	5 A	2 VDC	Silver Nickel (AgNi)		Flux Protection Sealed
TE Connectivity AMP Connectors 7-1415539-4	-40 °C	85 °C	General Purpose	8 ms	2000 VA	17.5 mA		1 C Form SPDT	cURus VDE	Non Latching	Through Hole	8 ms	PC Pin	9 VDC	400 VAC	5 A	12 VAC	Silver Nickel (AgNi)	685 Ohms
TE Connectivity AMP Connectors 3-1415390-1	-40 °C	85 °C	General Purpose	8 ms	2000 VA	18.5 mA		1 C Form SPDT	cURus VDE	Latching Single Coil	Through Hole	8 ms	PC Pin	9 VDC	400 VAC	5 A	12 VAC	Silver Nickel (AgNi)		Flux Protection Sealed
TE Connectivity AMP Connectors PE014024	-40 °C	85 °C	General Purpose	8 ms	2000 VA	8.8 mA		1 C Form SPDT	cURus VDE	Non Latching	Through Hole	8 ms	PC Pin	18 VDC	400 VAC	5 A	24 VDC	Silver Nickel (AgNi)	2.73 kOhms	Flux Protection Sealed	2.4 V
TE Connectivity AMP Connectors 1-1415395-1	-40 °C	85 °C	General Purpose	8 ms	2000 VA	23.4 mA		1 C Form SPDT	cURus VDE	Latching Single Coil	Through Hole	8 ms	PC Pin	6.75 VDC	400 VAC	5 A	9 VDC	Silver Nickel (AgNi)	385 Ohms	Flux Protection Sealed
TE Connectivity AMP Connectors 1-1393219-4	-40 °C	85 °C	General Purpose	8 ms	2000 VA	17.5 mA		1 C Form SPDT	cURus VDE	Non Latching	Through Hole	8 ms	PC Pin	9 VDC	400 VAC	5 A	12 VAC	Gold (Au) Silver Nickel (AgNi)	685 Ohms	Flux Protection Sealed	1.2 V
TE Connectivity AMP Connectors PE014012	-40 °C	85 °C	General Purpose	8 ms	2000 VA	17.5 mA		1 C Form SPDT	cURus VDE	Non Latching	Through Hole	8 ms	PC Pin	9 VDC	400 VAC	5 A	12 VAC	Silver Nickel (AgNi)		Flux Protection Sealed	1.2 V
TE Connectivity AMP Connectors 4-1415535-9	-40 °C	85 °C	General Purpose	8 ms	2000 VA	17.5 mA	1	SPST-NO	cURus VDE	Non Latching	Through Hole	8 ms	PC Pin	9 VDC	400 VAC	6 A	12 VAC	Silver Nickel (AgNi)	685 Ohms	Flux Protection Sealed	1.2 V
TE Connectivity AMP Connectors 5-1415535-5	-40 °C	85 °C	General Purpose	8 ms	2000 VA	8.8 mA		1 C Form SPDT	cURus VDE	Non Latching	Through Hole	8 ms	PC Pin	18 VDC	400 VAC	5 A	24 VDC	Silver Tin Oxide (AgSnO)	2725 Ohms	Flux Protection Sealed	2.4 V
