Specification	B43712A5109M000

Applications	General Purpose
Capacitance	10000 µF
ESR (Equivalent Series Resistance)	12 mOhm
Height - Seated (Max)	7.559 in
Impedance	20 mOhm
Lead Spacing	1.248 in
Lifetime	10000 Hrs
Mounting Type	Chassis Mount
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can - Screw Terminals, Radial
Polarization	Polar
Ripple Current	25.8 A, 2.56 A
Size / Dimension Diameter	3.543 in
Tolerance	20 %
Voltage - Rated	450 V
