Description

General part information

ZB5AK1353

ZB5AK1353 is a head for an illuminated selector switch. This orange illuminated switch head for integral LED provides an ergonomic interface for controlling your machines. It is supplied with a standard handle and can easily be installed on compatible selector switch units. It provides clear help in setting your machines in various operating modes, even in darker control rooms. It offers a clear visual feedback. It is impact-resistant, dust-resistant, water-resistant and vibration-resistant thanks to its IP69K. This makes it ideal for operation in harsh environments. It has standards like EN/IEC 60947-5-5, CSA C22.2 No 14, EN/IEC 60947-5-4, JIS C8201-5-1, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508, JIS C8201-1. It is certified by CSA, DNV, GL, LROS (Lloyds register of shipping), BV, UL listed.

Technical Specifications

Parameters and characteristics for this part

SpecificationZB5AK1353
Actuator TypeSelector
Compatible SeriesHarmony XB5, Schneider
IlluminationIlluminated
Panel Cutout Dimension22 mm
Panel Cutout ShapeRound
RequiresIllumination Source, Contact Block(s)
TypeMaintained
