Specification	1SNG602104R0000

Ingress Protection Description	Dust Tight, Waterproof
Ingress Protection IP Rating	IP68
Material	Polyamide (PA6), Nickel Plated, Nylon 6, Brass
Operating Temperature (Max)	100 °C
Operating Temperature (Min)	-20 °C
Outside Cable Diameter (Max)	0.63 in
Outside Cable Diameter (Min)	0.354 in
Panel Hole Size	1.299 in
Thread Length	0.472 in
Thread Size	PG21
Type	Cable Gland

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources
