Description
General part information
PYBE30-Q48-D5-U
Enclosed DC DC Converter 2 Output 5V -5V 3A, 3A 75V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | PYBE30-Q48-D5-U |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output (Max) | 3 A |
| Efficiency | 86 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 2 |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -40 °C |
| Power (Watts) | 30 W |
| Size / Dimension Height | 0.75 in |
| Size / Dimension Length | 2.17 in |
| Size / Dimension Width | 2.06 in |
| Standard Number | 62368-1 |
| Type | Enclosed |
| Voltage - Input (Max) | 75 V |
| Voltage - Input (Min) | 18 V |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 5 V |
| Voltage - Output 2 | -5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
