9926 0101000

Active

Belden Inc.

HOOK-UP STRND 26AWG BLACK

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 26AWG BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	9926 0101000

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand	7 Strands, 34 AWG
Jacket (Insulation) Diameter [diameter]	0.051 in
Jacket (Insulation) Diameter [diameter]	1.3 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.016 in
Jacket (Insulation) Thickness	0.41 mm
Jacket Color	Black
Length	1000 ft
Length	304.8 m
Ratings	UL Style 1007/1569
Voltage	300 V
Wire Gauge	26 AWG

Part	Jacket (Insulation) Material	Length	Length	Wire Gauge	Ratings	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Cable Type	Conductor Strand	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Voltage	Jacket Color	Length [x]	Length [x]
Belden Inc. 9926 0011000	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	26 AWG	UL Style 1007/1569	0.016 in	0.41 mm	Copper Tinned	Hook-Up	7 Strands 34 AWG	0.051 in	1.3 mm	300 V	Brown
Belden Inc. 9926 002100	Poly-Vinyl Chloride (PVC)			26 AWG	UL Style 1007/1569	0.016 in	0.41 mm	Copper Tinned	Hook-Up	7 Strands 34 AWG	0.051 in	1.3 mm	300 V	Red	30.5 m	100 ft
Belden Inc. 9926 0101000	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	26 AWG	UL Style 1007/1569	0.016 in	0.41 mm	Copper Tinned	Hook-Up	7 Strands 34 AWG	0.051 in	1.3 mm	300 V	Black
Belden Inc. 9926 0041000	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	26 AWG	UL Style 1007/1569	0.016 in	0.41 mm	Copper Tinned	Hook-Up	7 Strands 34 AWG	0.051 in	1.3 mm	300 V	Yellow
Belden Inc. 9926 0091000	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	26 AWG	UL Style 1007/1569	0.016 in	0.41 mm	Copper Tinned	Hook-Up	7 Strands 34 AWG	0.051 in	1.3 mm	300 V
Belden Inc. 9926 0051000	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	26 AWG	UL Style 1007/1569	0.016 in	0.41 mm	Copper Tinned	Hook-Up	7 Strands 34 AWG	0.051 in	1.3 mm	300 V	Green
Belden Inc. 9926 0131000	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	26 AWG	UL Style 1007/1569	0.016 in	0.41 mm	Copper Tinned	Hook-Up	7 Strands 34 AWG	0.051 in	1.3 mm	300 V	Blue

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 0.53

General part information

26 AWG Hook-Up Wire 7/34 Black 300V 1000.0' (304.8m)
