CBM-4010C-140-178
ActiveSame Sky (Formerly CUI Devices)
FAN BLOWER 39.5X10MM 12VDC WIRE
CBM-4010C-140-178
ActiveSame Sky (Formerly CUI Devices)
FAN BLOWER 39.5X10MM 12VDC WIRE
Description
General part information
CBM-4010C-140-178
Fan Blower 12VDC Square/Rounded - 39.5mm L x 39.5mm H omniCOOL™ Magnetic Sleeve 1.2 CFM (0.034mł/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CBM-4010C-140-178 |
|---|---|
| Air Flow | 1.2 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | omniCOOL™ Magnetic Sleeve |
| Current Rating | 0.08 A |
| Fan Type | Blower |
| Lifetime | 30000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 17.8 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 960 mW |
| RPM | 4000 RPM |
| Size / Dimension Height | 39.5 mm |
| Size / Dimension Length | 39.5 mm |
| Size / Dimension Shape | Square/Rounded |
| Static Pressure | 0.07 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 12 VAC |
| Voltage Range (Max) | 26.4 VDC |
| Voltage Range (Min) | 21.6 VDC |
| Width | 10 mm |
