ANT-915-NUB-SMA
ActiveTE Connectivity AMP Connectors
RF ANT 915MHZ SHORT WHIP SMA
ANT-915-NUB-SMA
ActiveTE Connectivity AMP Connectors
RF ANT 915MHZ SHORT WHIP SMA
Description
General part information
ANT-915-NUB-SMA
Terminal/Duck Antenna, Single Band, LPWAN / LoRaWAN, External Mount, Stud/Screw/Lug Mount, SMA, Omnidirectional, Single Port, 3 < 6 dBi Peak Gain
Technical Specifications
Parameters and characteristics for this part
| Specification | ANT-915-NUB-SMA |
|---|---|
| Antenna Type | Straight, Whip |
| Applications | ISM, LPWA, LoRaWAN |
| Frequency (Center/Band) | 915 MHz |
| Frequency Group | UHF |
| Frequency Group Maximum (UHF) | 1 GHz |
| Frequency Group Minimum (UHF) | 300 MHz |
| Frequency Range (Max) | 930 MHz |
| Frequency Range (Min) | 902 MHz |
| Gain | 3.9 dBi |
| Height (Max) | 0.697 in |
| Mounting Type | Connector Mount |
| Number of Bands | 1 |
| Power - Max | 25 W |
| RF Family/Standard | General ISM |
| Termination Type | SMA Male |
| VSWR | 2.6 |
