CS5.243

Active

PULS, LP

AC/DC DIN RAIL SUPPLY 24V 120W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CS5.243

Active

PULS, LP

AC/DC DIN RAIL SUPPLY 24V 120W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	CS5.243	CS5 Series

AC Voltage - Input	-	120 - 300 VAC
AC Voltage - Input	-	90 - 264 VAC
Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	CSA, EAC, ABS, DNV GL, IEC, UL	CSA, EAC, ABS, DNV GL, IEC, UL
Current - Output (Max) [Max]	5 A	5 A
DC Voltage - Input (Max)	-	300 V
DC Voltage - Input (Min)	-	264 V
Efficiency	90 %	90 - 90.2 %
Features	Adjustable Output, Load Sharing	Adjustable Output, Load Sharing, Conformal Coating
Input Type	AC	AC
Number of Outputs	1	1
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	-25 °C	-25 - 0 °C
Size / Dimension [x]	117 mm	117 mm
Size / Dimension [x]	4.61 "	4.61 "
Size / Dimension [y]	32 mm	32 mm
Size / Dimension [y]	1.26 in	1.26 in
Size / Dimension [z]	4.88 "	4.88 "
Size / Dimension [z]	124 mm	124 mm
Standard Number	61010-2-201, 60950-1, 508, Class I Div 2	61010-2-201, 60950-1, 508, Class I Div 2
Voltage - Isolation	500 V	500 V
Voltage - Output 1	24 V	24 V

CS5 Series

AC/DC DIN RAIL SUPPLY 24V 120W

Part	Current - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Approval Agency	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Input Type	DC Voltage - Input (Max) [Max]	Number of Outputs	Applications	Voltage - Output 1	Standard Number	DC Voltage - Input (Min) [Min]	Efficiency	Features	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Voltage - Isolation
PULS, LP CS5.244	5 A	-25 °C	70 °C	ABS, CSA, DNV GL, EAC, IEC, UL	4.88 "	32 mm	117 mm	124 mm	4.61 "	1.26 in	AC	300 V	1	ITE (Commercial)	24 V	508, 60950-1, 61010-2-201, Class I Div 2	264 V	90.2 %	Adjustable Output, Load Sharing	264 VAC, 300 VAC	180 VAC, 264 VAC	500 V
PULS, LP CS5.241-C1	5 A	-25 °C	70 °C	ABS, CSA, DNV GL, EAC, IEC, UL	4.88 "	32 mm	117 mm	124 mm	4.61 "	1.26 in	AC		1	ITE (Commercial)	24 V	508, 60950-1, 61010-2-201, Class I Div 2		90.2 %	Adjustable Output, Conformal Coating, Load Sharing	132 VAC, 264 VAC	90 VAC, 180 VAC	500 V
PULS, LP CS5.241	5 A	0 °C	70 °C	ABS, CSA, DNV GL, EAC, IEC, UL	4.88 "	32 mm	117 mm	124 mm	4.61 "	1.26 in	AC		1	ITE (Commercial)	24 V	508, 60950-1, 61010-2-201, Class I Div 2		90.2 %	Adjustable Output, Load Sharing	132 VAC, 264 VAC	90 VAC, 180 VAC	500 V
PULS, LP CS5.241-S1	5 A	-25 °C	70 °C	ABS, CSA, DNV GL, EAC, IEC, UL	4.88 "	32 mm	117 mm	124 mm	4.61 "	1.26 in	AC		1	ITE (Commercial)	24 V	508, 60950-1, 61010-2-201, Class I Div 2		90.2 %	Adjustable Output, Load Sharing	120 VAC, 240 VAC	100 VAC, 200 VAC	500 V
PULS, LP CS5.243	5 A	-25 °C	70 °C	ABS, CSA, DNV GL, EAC, IEC, UL	4.88 "	32 mm	117 mm	124 mm	4.61 "	1.26 in	AC		1	ITE (Commercial)	24 V	508, 60950-1, 61010-2-201, Class I Div 2		90 %	Adjustable Output, Load Sharing			500 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 238.50

Description

General part information

CS5 Series

AC/DC DIN RAIL SUPPLY 24V 120W

Documents

Technical documentation and resources
