HFWLF19-952T
ActiveAllied Components International
CMC 9.5MH 3A 2LN TH
HFWLF19-952T
ActiveAllied Components International
CMC 9.5MH 3A 2LN TH
Description
General part information
HFWLF19-952T
9.5 mH @ 100 kHz 2 Line Common Mode Choke Through Hole 3A DCR
Technical Specifications
Parameters and characteristics for this part
| Specification | HFWLF19-952T |
|---|---|
| Current Rating (Max) | 3 A |
| Height (Max) | 0.551 in |
| Inductance | 9.5 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature (Max) | 120 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | 4 PC Pin, Horizontal |
| Package Leads | 4 Leads |
| Package Name | Horizontal |
| Size / Dimension Length | 0.925 in |
| Size / Dimension Width | 0.846 in |
| Voltage Rating - AC | 250 V |
| Voltage Rating - DC | 250 VDC |
