Specification	B43630A9127M000

Applications	General Purpose
Capacitance	120 µF
ESR (Equivalent Series Resistance)	850 mOhm
Height - Seated (Max)	1.063 in
Impedance	1.3 Ohms
Lead Spacing	0.394 in
Lifetime	2000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-25 °C
Package / Case	Can - Snap-In, Radial
Polarization	Polar
Ripple Current	930 mA
Size / Dimension Diameter	0.866 in
Tolerance	20 %
Voltage - Rated	400 V
