Description
General part information
TPT3335-TS6R
3/5 Transceiver Full RS232 28-TSSOP
Technical Specifications
Parameters and characteristics for this part
| Specification | TPT3335-TS6R |
|---|---|
| Data Rate | 1 Mbps |
| Duplex | Full |
| Mounting Type | Surface Mount |
| Number of Drivers | 3 |
| Number of Receivers | 5 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package Length | 0.173 in |
| Package Name | 28-TSSOP |
| Package Width | 4.4 mm |
| Protocol | RS232 |
| Receiver Hysteresis | 300 mV |
| Type | Transceiver |
| Voltage - Supply (Maximum) | 5.5 V |
| Voltage - Supply (Minimum) | 3 V |
