EUROCARD TYPE M Series

Part	Style	Contact Finish	Termination	Number of Rows	Number of Positions Loaded	Level, Class	Connector Type	Number of Positions	Pitch	Mounting Type	Features	Material Flammability Rating	Operating Temperature (Max)	Operating Temperature (Min)	Material - Insulation	Number of Positions Loaded
TE Connectivity AMP Connectors 4-1393637-9
TE Connectivity AMP Connectors 4-1393637-6	C	Gold Gold-Palladium	Press-Fit	3	All	2	Female Sockets Receptacle	96	0.1 in	Through Hole	Board Guide	UL94 V-0	125 °C	-55 °C	Glass Filled PBT Polybutylene Terephthalate Polyester
TE Connectivity AMP Connectors 7-1393637-3	C	Gold Gold-Palladium	Press-Fit Wire Wrap	3	All	2	Female Sockets Receptacle	96	0.1 in	Through Hole		UL94 V-0	125 °C	-55 °C	Glass Filled PBT Polybutylene Terephthalate Polyester
TE Connectivity AMP Connectors 4-1393637-9	C	Gold Gold-Palladium	Press-Fit	3		2	Female Sockets Receptacle	96	0.1 in	Through Hole		UL94 V-0	125 °C	-55 °C	Glass Filled PBT Polybutylene Terephthalate Polyester	64
TE Connectivity AMP Connectors 2-1393637-9	C	Gold Gold-Palladium	Press-Fit Wire Wrap	3	All	2	Female Sockets Receptacle	96	0.1 in	Through Hole		UL94 V-0	125 °C	-55 °C	Glass Filled PBT Polybutylene Terephthalate Polyester
TE Connectivity AMP Connectors 4-1393637-4	C/2 (1/2 C)	Gold Gold-Palladium	Press-Fit	3	All	2	Female Sockets Receptacle	48	0.1 in	Through Hole		UL94 V-0	125 °C	-55 °C	Glass Filled PBT Polybutylene Terephthalate Polyester

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
