Specification	B43504A0107M000

Applications	General Purpose
Capacitance	100 µF
ESR (Equivalent Series Resistance)	1.35 Ohm
Height - Seated (Max)	1.457 in
Impedance	1.6 Ohms
Lead Spacing	0.394 in
Lifetime	3000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can - Snap-In, Radial
Polarization	Polar
Ripple Current	640 mA
Size / Dimension Diameter	0.866 in
Tolerance	20 %
Voltage - Rated	420 V
