C-49U
ActiveTriad Magnetics
SURFACE MOUNT POWER INDUCTOR, C SERIES, 32 MH, 10 A, 0.19 OHM, -20% TO +50%
C-49U
ActiveTriad Magnetics
SURFACE MOUNT POWER INDUCTOR, C SERIES, 32 MH, 10 A, 0.19 OHM, -20% TO +50%
Description
General part information
C-49U
32 mH Unshielded Wirewound Inductor 5 A 28mOhm Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | C-49U |
|---|---|
| Current Rating | 5 A |
| DC Resistance (DCR) | 28 mOhm |
| Height - Seated (Max) | 4.25 in |
| Inductance | 32 mH |
| Inductance Frequency - Test | 120 Hz |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 3.5 in |
| Size / Dimension Width | 3.625 in |
| Tolerance (Negative) | 20 % |
| Tolerance (Positive) | 50 % |
| Type | Wirewound |
